Temperature and Humidity Sensor Breakout for Arduino

SKU: Z6320
A compact 5V temperature and humidity sensor add-on for Arduino. DHT22.
$21.95

All Prices Shown are (inc GST)
Bulk Pricing
ea $21.95
2+ $19.75
4+ $17.75
i h

Overview

A compact 5V temperature and humidity sensor add-on for Arduino. A product for Arduino that works with official Arduino boards. Suitable for Arduino SCM. The device has an output calibrated digital signal. It utilizes exclusive digital-signal-collecting-technique and humidity sensing technology, assuring its reliability and stability. Its sensing elements are connected with 8-bit single-chip computer.

Every sensor of this model is temperature compensated and calibrated in accurate calibration chamber and the calibration-coefficient is saved in type of programme in OTP memory, when the sensor is detecting, it will cite coefficient from memory. Small size & low consumption & long transmission distance (20m) enable device to be suited in all kinds of harsh application occasions. Single-row packaged with four pins, making the connection very convenient.







Specifications:



Power supply: 3.3-6V DC

Output signal: Digital signal via single-bus

Sensing element: Polymer humidity capacitor & DS18B20 for detecting temperature

Measuring range: humidity 0-100%RH; temperature -40~125°C

Accuracy: humidity +-2%RH(Max +-5%RH); temperature +-0.2°C

Resolution or sensitivity: Humidity 0.1%RH; temperature 0.1°C

Repeatability: Humidity +-1%RH; Temperature +-0.2°C

Humidity hysteresis: +-0.3%RH

Long-term Stability: +-0.5%RH/year

Sensing period: Average: 2s

Interchangeability: Fully interchangeable



Features:

  • Full range temperature compensated
  • Relative humidity and temperature measurement
  • Calibrated digital signal
  • Outstanding long-term stability
  • Extra components not needed
  • Long transmission distance
  • Low power consumption
  • 4 pins packaged and fully interchangeable



Details

Products specifications

Warranty 12 Months
Barcode 9321758169766
Weight (Kg) 0.011
